H.265 POE HD 3MP Mini Type IP Camera 1296P / 1080P Indoor Security ONVIF P2P CCTV System Video Surveillance Cam
zoom_out_map
chevron_left chevron_right

H.265 POE HD 3MP Mini Type IP Camera 1296P / 1080P Indoor Security ONVIF P2P CCTV System Video Surveillance Cam

H.265 POE HD 3MP Mini Type IP Camera 1296P / 1080P Indoor Security ONVIF P2P CCTV System Video Surveillance Cam

  • POE 48V
  • DC 12V
  • 2.8mm
  • 3.6mm
  • 6mm
  • 8mm
EUR€ 34.95 (tax incl.) EUR€ 34.95 (tax excl.)
Tax included
check In-stock

H.265 POE HD 3MP Mini Type IP Camera 1296P / 1080P Indoor Security ONVIF P2P CCTV System Video Surveillance Cam

-3MP 2304*1296P resolution
- Support H.265 encode, compare with H.264, transit same quality image only need half of the bandwidth; Record same quality image only need half of the storage;
- Also support H.264 encode,  so it can be compatible with both H.264 and H.265 device.
- Support POE, reduce the trouble of cable arrangement.
- Have auxiliary power supply, can use like a Non-POE IP camera.
- Support iPhone, Android smart phone
- P2P Cloud Function
- Support Motion Detection, Email Alarm function
- Support Multi-Language
- Net Weight: 0.2KG
- Metal Material Shell
- Simple Operation and Easy to Use
-Note:
1. IP camera will create more heat and the case of this camera is small, so after you operate the camera for a while, you will feel the camera is hot. And do not worry, it is normal and safe, hope you can understand.
2.This camera default 3MP & H.265, if your NVR do not support 3MP or H.265, you can change our camera into 1080P (2MP) and H.264.
3."POE 48V" Option mean the camera support POE, can power from POE, need to connect with a 802.3AF Standard 48V POE Switch (It have auxiliary power supply connector, can be used like a Non-POE IP camera).
4."DC 12V" Option mean the camera is regular version, do not support POE and it can only with with a 12V regular power.
Camera


Model: I706-FHW

Resolution:2304 x 1296P 3.0mega Pixels camera

Sensor: FH8852 + GC2053

Min illumination: 0.1Lux @(F1.2,AGC ON)

Frame rate: 20 fps

Shutter: 1/25 seconds -1/100,000 seconds

Lens: 2.8mm, 3.6mm, 6mm, 8mm

Lens interface type: M12

Digital noise reduction: 3D Digital noise reduction

Compression Format: H.264 / H.265

Compression rate output: 128 Kbps~8Mbps

Storage: NVR or Computer

IP address: Dynamic (Default) / Static

Smart alarm: Motion detection, Email alarm, CMS alarm

Support protocol: HTTP, TCP/IP, ICMP.RTSP, RTP, RTCP, SMTP, DHCP, DNS, PPPoE, NTP

Input protocol: The standard ONVIF

General function: A key recovery, dual stream, password protection, video hiding

Ethernet: 10M / 100M mbps Ethernet (RJ-45)



General


Operating Temperature: -25°C~60°C

Operating Humidity: 10%~90%

Power Supply:

POE 48V option support POE 48V(802.3af) & DC12V/2A

DC 12V option support DC12V/2A

POE Standard: 802.3af

Housing Material:Metal

Dimension:5.3 x 4.5x 4cm

Weight: 0.2kg



Package Content

1 x Camera
1 X User Manaul
1 x Screws Set


Power supply Note:

1.POE 48V version can power from POE, need to connect with a802.3AF Standard 48V POE Switch. if you need one, please click the picture to buy.



2.Both POE 48V version and DC 12V version have not include power adapter, if you need one, please click the picture to buy.



Daytime + Indoor

Night with light + Indoor

Browser View:

CMS ViewCMS View

How to download and use the CMS? Please click here to know it.

Support Multi-Language.




App View

How to download and use the APP? Please click here to know it.



NOTENOTE:System 1 also can save the video by CMS software, but it need to set and open the computer all the time. It is not convenient, so we suggest your to use system 2 to save the video. It is stable and reliable.

Surveillance Camera D
Brand Name
REVOTECH
Origin
Mainland China
Style
Mini Camera
Model Number
I706-FHW
Type
CCTV Camera
Color
Black
Certification
CE
Place Of Origin
Guangdong, China (Mainland)
is_customized
Yes
colour
Black
resolution
3MP / 1080P
Model
IP Camera
Year
2022
Technology
Mini
High Definition
3.0 Megapixels
Supported Operating Systems
Windows 10,Windows Vista,Windows 8,Windows 7,Windows 98,windows xp
Lens (mm)
8mm,6mm,3.6mm,2.8mm
Connectivity
IP/Network Wired
Installation
Ceiling
Minimum Illumination(Lux)
NA
Megapixels
3MP
Storage
None
Video Compression Format
H.264,H.265
IR Distance(m)
0
Dimensions (L x W x D)(mm)
5.3x 4.5 x 4cm
Alarm Action
Email Photo
Supported Mobile Systems
iOS,Android
Smart home platform
NONE
TF Card
None
Power Supply(V)
POE48V / DC12V
Audio Output
None
Power Consumption(W)
48W
Sensor
CMOS
Power Supply
With POE
Lens
2.8mm, 3.6mm, 6mm, 8mm
TV Format
PAL/NTSC
White Balance
Auto
Status
Brand New
