VEVOR MD40 Magnetic Drill Press 40mm for Engineering Steel Structure 1100W Height Adjustable Electric Bench Drilling Rig Machine
VEVOR MD40 Magnetic Drill Press 40mm for Engineering Steel Structure 1100W Height Adjustable Electric Bench Drilling Rig Machine
Electric Magnetic Drill Press
This class of leading drill press tools has been designed and engineered specifically for speed and precision, with solid magnetic adhesion of 12000 N, an optimized rotation speed of 550 RPM. It is an essential tool for performing heavy-duty industrial and steel fabrication work.
NOTE: Our magnetic drill can only be used with hollow boring bits, not with annular bits.
- Superior Performance
- Premium Coring Bits & Cooling Pot
- 12,000 N Magnetic Force
- User-Friendly Design
- Various Applications
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR's products are sold in more than 200 countries and regions with 10 million plus members worldwide.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Key Features
Excellent Performance
Designed for precise and demanding coring, this mag drill features 550 rpm and 1100 watts of motor power. Max. Coring Diameter: 1.57'' (40 mm); Max. Coring Depth: 5'' (125 mm). And our magnetic drill can only be used with hollow boring bits, not with annular bits.
Superior Accessories
11 coring bits meet different working requirement, and it can be installed directly without drill clip. Also, there are a stainless steel coolant pot and a pilot pin provided for your convenient operation.
12,000 N Suction Power
The stable base acts as a powerful electromagnet to firmly fix the drill bit at a force of 2700 pounds (12,000 N) during work, preventing movement during drilling process.
-
Double Dovetail Guide Rail
The wear resistance of this double dovetail guide rail is better than that of ordinary guide rails, it increases the rigidity and improves the wear resistance of the magnetic drilling machine.
Considerable Details
The crank handles are coated with non-slip rubber, which makes the operation easy and labor-saving. The ergonomically designed handle provides a comfortable grip. A simple control panel allows easy operation.
The electromagnetic drill press plays a vitally important role in shipbuilding, equipment manufacturing, equipment installation, bridge engineering, and other engineering facilities
- Maximum Boring Diameter: 1.57″ (40mm)
- Maximum Boring Depth: 5″ (125mm)
- Voltage: 110V(US) / 230V(EU/AU)
- Rated Frequency: 60/50 Hz
- Rated Input Power: 1100 W
- Spindle Speed (No-load Speed): 550 RPM
- Stainless-Steel Pot: 21.36 Cubic Inch/350ml
- 2700 lbs (12000 N) Max Magnetic Force** (Thinner Metal = Less Force)
- Toolholder: 3/4 in(19.05 mm) Weldon Shank
- Overall Weight: 30 Lbs (13.6 Kg)
Package Content
- 1 X MD40 Magnetic Drill Press
- 7 X Core Drill Bit (0.47" x 1"/12mm x 26mm, 0.51" x 1"/13mm x 26mm, 0.59" x 1"/15mm x 26mm, 0.63" x 1"/16mm x 26mm, 0.71" x 1"/18mm x 26mm, 0.79" x 1"/20mm x 26mm, 0.82" x 1"/21mm x 26mm)
- 4 X Core Drill Bit (0.90" x 1"/23mm x 26mm, 0.94" x 1"/24mm x 26mm, 1.02" x 1"/26mm x 26mm, 1.06" x 1"/27mm x 26mm)
- 1 X Stainless-Steel Pot
- 1 X Pilot Pin
- 1 X Rope
- 1 X User's Manual
Features & Details
- Superior Performance: Our portable drill press generates exceptionally strong power thanks to its 1100W copper motor. It is capable of drilling into toughest materials at 550 RPM. Maximum Coring Diameter: 1.57'' (40 mm); Maximum Coring Depth: 5'' (125 mm). Besides, our magnetic drill can only be used with hollow boring bits, not with annular bits.
- Premium Coring Bits & Cooling Pot: There are 11 chisel bits: 12mm, 13mm, 15mm, 16mm, 18mm, 20mm, 21mm, 23mm, 24mm, 26mm, 27mm, meeting a variety of demands for coring. Also, we provide you a rust-proof stainless steel cooling pot and a pilot pin. The pilot pin can remove screws and assist in the installation & removal of bits.
- 12,000 N Magnetic Force: The powerful two-stage magnet can generate 12,000 N of holding force, ensuring the drill press machine will not move in the work. Thanks to its Electromagnet base, our magnetic drill press anchor itself securely during use through its solid iron bottom.
- User-Friendly Design: The double dovetail rail adds rigidity and improves the wear resistance of magnetic drill press. This ergonomic design handle provides comfortable grip in operation and transport. These 3 extended crank handles are coated with nonslip rubber for labour-saving operation.
- Various Applications: This versatile magnetic drill press is immensely suitable for industrial and steel fabrication, ship or bridge building, railway manufacture, wind power generation, power-plant construction, home improvement, equipment installation, and a wide swath of other fields.
 |
 |
 |
 |
 |
|
|---|---|---|---|---|---|
| MB23 Magnetic Drill Press | MD35 Magnetic Drill Press | MD40 Magnetic Drill Press | MD40 Magnetic Drill Press | MD40 Magnetic Drill Press | |
| Max Drill Size | 23mm (0.9 inch) | 35mm (1.37 inch) | 40mm (1.5 inch) | 40mm (1.5 inch) | 40mm (1.5 inch) |
| Max Travel | 210mm (8.3 inch) | 125mm (5 inch) | 140mm (5.5 inch) | 140mm (5.5 inch) | 140mm (5.5 inch) |
| Magnetic Adhesion | 13000N (2920LBS) | 12000N (2700LBS) | 12500N (2810LBS) | 12500N (2810LBS) | 12500N (2810LBS) |
| Rated Voltage | 110V(US)/220V(EU/AU) | 110V(US)/220V(EU/AU) | 110V(US)/220V(EU/AU) | 110V(US)/220V(EU/AU) | 110V(US)/220V(EU/AU) |
| Rated Output | 1200W | 980W | 1100W | 1100W | 1100W |
| Core Drill Bits | / | / | / | 6 Pcs | 11 Pcs |
- Brand Name
- VEVOR
- Origin
- Mainland China
- Model Number
- MD40
- Type
- Power Drills
- Application
- equipment manufacturing installation
- Certification
- CE
- Weight
- 30 Lbs (13.6 Kg)
- Power Source
- AC
- Usage
- Commercial Manufacture
- Frequency
- 50/60Hz
- Voltage
- 110V(US) / 230V(EU/AU)
- Drill Type
- Magnetic Drill
- Max. Drilling Diameter
- 1.57Inch / 40mm
- Rated Input Power
- 1100W
- Rated Frequency
- 60/50 Hz
- Corded/ Cordless
- Corded
- Maximum Boring Depth
- 5Inch / 125mm
- Spindle Speed (No-load Speed)
- 550 RPM
- Tool Holder
- 3/4Inch Weldon Shank
- Max Magnetic Force
- 2,700 lbs (12,000 N)
- Cutter kit
- 11 Drill Bits,1 Pot,1 Pilot Pin
